歡迎來到蘇州奧賽特液壓升降機械有限公司網站!

該產品適用于各行業高空設備安裝、檢修等高空作業。它采用剪叉式機械結構,使升降臺起升后有較高的穩定性。










 參數表:

Description typeLoad CapacityPlatformOwn heightLift HeightMax HeightPowerVoltage
型號負荷能力平臺尺寸自身高度升降行程最大高度電機功率電源電壓
KgL長*W寬(MM)(MM)(MM)(MM)kwV
固定式液壓升降平臺
SJG0.3-0.5300900*3502005007000.75380V
SJG0.5-0.5500900*3802005007001.1380V
SJG1-0.9710001500*100023097012001.5380V
SJG1-1.510002500*2000340150018402.2380V
SJG1.5-1.215002000*1500350120015502.2380V
SJG2-120001600*1000300100013002.2380V
SJG2-1.620002500*2000360160019603380V
SJG3-130001600*1200360100013603380V
SJG4-1.240002400*1200400120016004380V
SJG5-1.550002600*2000480150019804380V
SJG6-1.260002000*2000480120016804380V
SJG8-180001600*1600500100015004380V
SJG10-1.6100003500*2200680160022805.5380V
SJG15-1.6150003500*2200780160023807.5380V
SJG20-1.8200006000*2500720180025207.5380V
SJG30-1.6300007000*30008801600248011380V
